Cisco IOS Voice, Video, and Fax Commands: R Through Sh
show voice port
VR-836
Cisco IOS Voice, Video, Fax Command Reference
For the Cisco MC3810 Multiservice Concentrator with Digital Voice Ports:
For the Cisco AS5300 Access Server :
For the Cisco AS5800 Universal Access Server:
For the Cisco 7200 Series Router:
Defaults No default behavior or values.
slot:ds0-group (Optional) Displays information for the digital voice port you
specify with the slot:ds0-group designation.
• slot specifies the module (and controller). Valid entries are
0 for the MFT (controller 0) and 1 for the DVM (controller
1).
• ds0-group specifies a T1 or E1 logical voice port number.
Valid entries are from 0 to 23 for T1 and from 0 to 30 for
E1.
summary (Optional) Displays a summary of all voice ports.
controller number Specifies the T1 or E1 controller.
:D Indicates the D channel associated with ISDN PRI.
shelf/slot/port Specifies the T1 or E1 controller on the T1 card. Valid entries
for the shelf argument are from 0 to 9999. Valid entries for the
slot argument are from 0 to 11. Valid entries for the port
argument are from 0 to 11.
shelf/slot/parent:port Specifies the T1 controller on the T3 card. Valid entries for the
shelf argument are from 0 to 9999. Valid entries for the slot
argument are from 0 to 11. Valid entries for the port argument
is 1 to 28. The value for the parent argument is always 0.
:D Indicates the D channel associated with ISDN PRI.
slot The router location where the voice port adapter is installed.
Valid entries are from 0 to 3.
port Indicates the voice interface card location. Valid entries are 0
and 1.
dso-group-no Indicates the defines DS0 group number. Each defined DS0
group number is represented on a separate voice port. This
allows you to define individual DS0s on the digital T1/E1 card.
slot-number Indicates the slot number in the Cisco router where the voice
interface card is installed. Valid entries are from 0 to 3,
depending on the slot where it has been installed.
subunit-number Indicates the subunit on the voice interface card where the voice
port is located. Valid entries are 0 and 1.
port Indicates the voice port number. Valid entries are 0 and 1.
