Checking files
The files selected are inspected for formal input errors
and for geometrical deviations.
The job identification for the three input files is
inspected, as are possible errors in the data format e.g.
missing or incorrect word index (WI). Errors are
indicated by appropriate messages. The inspection can
be continued or interrupted. If serious formal errors
are found, the inspection is aborted.
Geometrical deviations include the tangent directions
of adjacent elements and the chord lengths of elements.
Deviations which exceed the permitted tolerance are
displayed. The inspection of the files can be continued
or interrupted.
After inspection, the program returns to Dialog 2. The
input values can be corrected, either on a PC using the
program "ROADDATA.EXE" or on the TPS1000 using
the programm "FILE EDITOR".
ROADL\ CHECKING FILES
14:03
MC
NO YES
F1
F2 F3
F4
F5 F6
ALN: Deflection tolerance
exceeded at chainage 89°18'00".
Difference in direction is
0°00'27". Override?
