Section 1
General Information
Specifications, Ratings & Dimensions 7-7MN722
Dimensions
Size C+ Control
28.32
(719.3)
29.25
(743.0)
30.00
(762.0)
5.25
(133.3)
11.50
(292.1)
0.40
(10.2)
0.50
(12.7)
12.00(304.8)
12.20(309.9mm)
0.31
(7.9)
.31(7.9mm)
LIFTING
FLANGE
JOG LOCAL PROG
FWD
DISP
REV SHIFT ENTER
RESETSTOP
5.25
(133.3)
AIR INLET (Bottom)
AIR OUTLET
AIR INLET (Top)
AIR OUTLET
AIR OUTLET
AIR OUTLET AIR OUTLET
Note:
An internal baffle divides the enclosure into two parts.
The upper and lower parts each have separate air
inlets and outlets as shown.
Allow 2 inches minimum clearance on all sides
for ventilation.
AIR INLET
(Bottom)
