A P P E N D I X A
Remotelymanagingyour systemthrough anetworkinterface
47 smarttech.com/kb/170549
Submenu setting Description
Restore All Projector
Defaults
Returns projector settings to default values or refreshes the current
settings. Select Submit or Refresh.
I M P O R T A N T
The Submit option is irreversible and resets all values.
Volume Adjusts the projector’s volume from -20 to 20.
Mute Turns on or turns off the mute settings. Select On to mute the
projector’s sound and Off to turn off mute.
Volume Control Enables volume control. Select On to enable volume adjustment and
select Off to disable volume adjustment if you prefer to use your
audio system or speaker (not included) controls.
Closed Captioning Turns on or turns off the closed captioning feature.
Language Sets the closed captioning language to CC1 or CC2.
Typically, CC1 displays U.S. English subtitles, while CC2 displays
other regional languages, such as French or Spanish, depending on
television channel or media setup.
Display Mode Adjusts the display output to SMART Presentation, Bright Room,
Dark Room, sRGB and User modes so you can project images from
various sources with consistent color performance:
l
SMART Presentation is recommended for color fidelity.
l
BrightRoom and DarkRoom are recommended for locations
with those conditions.
l
sRGB provides standardized accurate color.
l
User enables you to apply your own settings.
Brightness Adjusts projector brightness from 0 to 100.
Contrast Adjusts the difference between the lightest and darkest parts
of the image from 0 to 100.
Frequency Adjusts the display data frequency of the projected image from
-5 to 5 to match the frequency of your computer’s graphics card.
Tracking Synchronizes your projector’s display timing with your computer’s
graphics card from 0 to 31.
Sharpness Adjusts the projected image’s sharpness from 0 to 31.
White Peaking Adjusts the image color brightness from 0 to 10 while providing more
vibrant white shades. A value closer to 0 creates anatural image and
a value closer to 10 enhances brightness.
Degamma Adjusts the color performance of the display from 0 to 3.
