C H A P T E R 3
Usingyour interactive whiteboardsystem
13 smarttech.com/kb/170549
Setting Use Notes
V-Position Moves the vertical position of
the source video up or down
from -5to 5 (relative to the
projected image).
Don’t adjust this setting unless you’re advised
to by SMARTSupport.
Apply this setting only after you make all boom
adjustments.
This setting applies to VGA inputs only and is
useful in situations where the source video is
cut off.
White Peaking Adjusts the image color
brightness from 0 to 10 while
providing more vibrant white
shades.
A value closer to 0 creates anatural image and
a value closer to 10 enhances brightness. The
default is 10.
Degamma Adjusts the color performance
of the display from 1 to 3.
The default is 2.
Color Adjusts the Red, Green, Blue,
Cyan, Magenta and Yellow
colors on the projector from 0 to
100 to provide custom color and
luminance output.
Each color has adefault value of 100.
Adjustments to the color settings register
under the User mode.
Audio menu
Volume Adjusts the projector’s volume
amplification from -20 to 20.
The default is 0.
Mute Mutes the projector’s audio
output.
The default is off.
If you mute the projector’s audio output and
then increase or decrease the volume, the
volume is restored automatically. You can
prevent this from happening by disabling the
volume control.
Disable Volume
Control
Disables the projector’s volume
control.
Line out
Enables or disables the line out. The default is on
Microphone Enables or disables the
microphone
The default is on
Speaker Enables or disables the speaker
The default is on
