C H A P T E R 3
Usingyour interactive whiteboardsystem
16 smarttech.com/kb/170549
Setting Use Notes
DHCP Displays the status of the
network’s Dynamic Host
Configuration Protocol (DHCP)
as On or Off.
The default is on.
On enables a DHCP server on the network to
automatically assign an IP address to the
projector.
Off enables an administrator to assign an IP
address manually.
Password
Reminder
E-mails the network password
to the predefined e-mail
recipient.
See Web page management on page 45 to set
up a destination e-mail address.
IP Address Displays the projector’s current
IP address in values between
0.0.0.0 and 255.255.255.255.
To change the projector’s IP address, use the
RS-232 connector (see Network information
on page 65) or use a DHCP server to assign a
dynamic IP address, and then set astatic IP
address using the network remote
management feature (see Remotely managing
your system through a network interface on
page 45).
Subnet Mask Displays the projector’s subnet
mask number in values between
0.0.0.0 and 255.255.255.255.
Gateway Displays the projector’s default
network gateway in values
between 0.0.0.0 and
255.255.255.255.
DNS Displays the projector’s primary
domain name server (DNS) IP
address in values between
0.0.0.0 and 255.255.255.255.
MAC Address Displays the projector’s MAC
address in xx-xx-xx-xx-xx-xx
format.
Group Name Displays the projector’s
workgroup name as set by an
administrator (maximum 12
characters).
You can set the projector’s workgroup name
using the remote management features (see
Remotely managing your system through a
network interface on page 45 and Remotely
managing your system through an RS-232
serial interface on page 53).
