CHAS
6 - 44
REAR SHOCK ABSORBER, SWINGARM AND
DRIVE CHAIN
Order Job/Part Q’ty Remarks
9 Drive chain case 1 1
10 Lock washer 1
11 Drive sprocket 1
12 Drive chain 1
13 Dust cover
15 Bushing 1
16 Spacer 2
For installation, reverse the removal
procedure.
Refer to “INSTALLING THE DRIVE
SPROCKET”.
2
14 Drive chain guide 2
T
R
.
.
35 Nm (3.5 m • kg, 25.3 ft • Ib)
T
R
.
.
35 Nm (3.5 m • kg, 25.3 ft • Ib)
T
R
.
.
75 Nm (7.5 m • kg, 54.2 ft • Ib)
T
R
.
.
10 Nm (1.0 m • kg, 7.2 ft • Ib)
1
2
3
4
5
6
7
9
10
14
13
13
15
15
16
T
R
.
.
18 Nm (1.8 m • kg, 13.0 ft • Ib)
8
11
12
