Controlling the Virtual Patch1…Patch6 Destination
• Dest1…Dest6: [Bn, 63, 04, Bn, 62, 08…0D, Bn, 06, mm]
(n: channel, mm: parameter value)
Controlling the vocoder parameters
These messages are transmitted and received on the Global MIDI channel.
Fc Modulation Source
FC.MOD.SRC (Fc Modulation Source): [Bn, 63, 04, Bn, 62, 00, Bn,
06, mm]
(n: channel, mm: parameter value)
Band parameters
You can control the output level and pan for each band of the vocoder’s
synthesis filter.
Level1...Level16: [Bn, 63, 04, Bn, 62, 40...4F, Bn, 06, mm]
(n: channel, mm: parameter value)
Pan1...Pan16: [Bn, 63, 04, Bn, 62, 50...5F, Bn, 06, mm]
(n: channel, mm: parameter value)
If you want to transmit and receive these parameters between two
microKORG XL unit
s, make the same program settings on both the
transmitting and receiving units.
MSB
(Hex)
LSB
(Hex)
Value
(transmitted)
Value
(received)
Patch1
Dest
04(04) 08(08)
0...2: Pitch,
3...5: OSC2 Tune,
6...9: OSC1 Control 1,
10...12: OSC1 Level,
13...15: OSC2 Level,
16...18: NOISE Level,
19...21: Filter1 Type Balance,
22...25: Filter1 Cutoff,
26...28: Filter1 Resonance,
29...31: Filter2 Cutoff,
32...34: Drive/WS Depth,
35...37: AMP Level,
38...41: Panpot,
42...44: LFO1 Frequency,
45...47: LFO2 Frequency,
48...50: Portamento,
51...53: OSC1 Control 2,
54...57: Filter1 EG1 Int,
58...60: Filter1 Key Track,
61...63: Filter2 Resonance,
64...66: Filter2 EG1 Int,
67...69: Filter2 Key Track,
70...73: EG1 Attack,
74...76: EG1 Decay,
77...79: EG1 Sustain,
80...82: EG1 Release,
83...85: EG2 Attack,
86...89: EG2 Decay,
90...92: EG2 Sustain,
93...95: EG2 Release,
96...98: EG3 Attack,
99...101: EG3 Decay,
102...105: EG3 Sustain,
106...108: EG3 Release,
109...111: Patch1 Int,
112...114: Patch2 Int,
115...117: Patch3 Int,
118...121: Patch4 Int,
122...124: Patch5 Int,
125...127: Patch6 Int
0...2: Pitch,
3...5: OSC2 Tune,
6...9: OSC1 Control 1,
10...12: OSC1 Level,
13...15: OSC2 Level,
16...18: NOISE Level,
19...21: Filter1 Type Balance,
22...25: Filter1 Cutoff,
26...28: Filter1 Resonance,
29...31: Filter2 Cutoff,
32...34: Drive/WS Depth,
35...37: AMP Level,
38...41: Panpot,
42...44: LFO1 Frequency,
45...47: LFO2 Frequency,
48...50: Portamento,
51...53: OSC1 Control 2,
54...57: Filter1 EG1 Int,
58...60: Filter1 Key Track,
61...63: Filter2 Resonance,
64...66: Filter2 EG1 Int,
67...69: Filter2 Key Track,
70...73: EG1 Attack,
74...76: EG1 Decay,
77...79: EG1 Sustain,
80...82: EG1 Release,
83...85: EG2 Attack,
86...89: EG2 Decay,
90...92: EG2 Sustain,
93...95: EG2 Release,
96...98: EG3 Attack,
99...101: EG3 Decay,
102...105: EG3 Sustain,
106...108: EG3 Release,
109...111: Patch1 Int,
112...114: Patch2 Int,
115...117: Patch3 Int,
118...121: Patch4 Int,
122...124: Patch5 Int,
125...127: Patch6 Int
Patch2
Dest
04(04) 09(09)
Patch3
Dest
04(04) 10(0A)
Patch4
Dest
04(04) 11(0B)
Patch5
Dest
04(04) 12(0C)
Patch6
Dest
04(04) 13(0D)
Fc Mod Sorce Value (transmitted) Value (received)
EG1 0...10 0...10
EG2 11...20 11...20
EG3 21...31 21...31
LFO1 32...42 32...42
LFO2 43...52 43...52
Velocity 53...63 53...63
Pitch Bend 64...74 64...74
Mod Wheel 75...84 75...84
Keyboard Track 85...95 85...95
MIDI1 96...106 96...106
MIDI2 107...116 107...116
MIDI3 117...127 117...127
