3. When Wave: Noise, and OSC1 Mod: Waveform
Control1: Resonance ............................................................[000…127]
This parameter adjusts the amount of resonance of the filter provided within
the noise oscillator. Higher values will emphasize the frequency points for
the pitched component within the noise.
Control2: LPF/HPF Mix.........................................[LPF63…CNT…HPF63]
This parameter adjusts the mix balance between the low-pass and high-
pass filters; this will vary the brightness of the sound.
4. When Wave: PCM/DWGS and OSC1 Mod: Waveform
Control1: .................................................................. --- (HAS NO EFFECT)
Control2: Wave Select.............................................................[001…64]
Selects the PCM/DWGS waveform.
*: The waveform number 2: For ROSE EP, the strength of the note velocity
will switch the PCM waveform that is sounded.
**:The waveform number 60: Endless simulates the “infinite staircase”
sound which produces the same perceived pitch in each different
octave. The “infinite staircase” produces the sensation that you never
get any higher, no matter how long you continue playing the notes C, D,
E, F, G, A, B, C, D, E, ... upward.
5. When Wave: Audio In and OSC1 Mod” Waveform
Control1: Gain.................................................................... [–63…+63]
This parameter adjusts the volume of the audio input.
Control2: ..................................................................--- (HAS NO EFFECT)
6. When Wave: Saw, Pulse, Triangle, Sine and OSC1 Mod: Cross
Control1: Modulation Depth................................................. [000…127]
This parameter adjusts the cross modulation depth.
No. PCM/DWGS Name No. PCM/DWGS Name
1 APIANO 33 SYNSINE5
2 ROSE EP * 34 SYNSINE6
3 WURLY EP 35 SYNSINE7
4 VPM EP1 36 SYNWAVE1
5 VPM EP2 37 SYNWAVE2
6 CLAV1 38 SYNWAVE3
7 CLAV2 39 SYNWAVE4
8 CLAV3 40 SYNWAVE5
9 ORGAN1 41 SYNWAVE6
10 ORGAN2 42 SYNWAVE7
11 ORGAN3 43 SYNWIRE1
12 M1ORGAN 44 SYNWIRE2
13 FULORGAN 45 SYNWIRE3
14 VOXORGAN 46 SYNWIRE4
15 PIPEORG 47 5THSAW
16 STRINGS 48 5THSQU
17 BRASS 49 DIGI1
18 GUITAR1 50 DIGI2
19 GUITAR2 51 DIGI3
20 BASS1 52 DIGI4
21 BASS2 53 DIGI5
22 BASS3 54 DIGI6
23 BELL1 55 DIGI7
24 BELL2 56 DIGI8
25 BELL3 57 DIGI9
26 SYNPAD1 58 SYNVOX1
27 SYNPAD2 59 SYNVOX2
28 SYNPAD3 60 ENDLESS **
29 SYNSINE1 61 NOISE1
30 SYNSINE2 62 NOISE2
31 SYNSINE3 63 NOISE3
32 SYNSINE4 64 NOISE4
No. PCM/DWGS Name No. PCM/DWGS Name
