Effect guide
79
17. GRAIN.SFT (Grain Shifter)
+
Left
Right
Sample Cycle
Dry / Wet
Dry / Wet
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
LFO
Grain Shifter
This effect samples extremely brief fragments of the sound at a specified
interval, and plays them as a loop. This is effective when used on external
input sounds that are constantly changing.
DRY/WET ......................................................["DRY", 99:1…1:99, "WET"]
Sets the balance between the effect and dry sounds.
BPM SYNC (Duration Tempo Sync)..............................................[OFF, ON]
Specifies whether playback of the looped waveform will be synchronized.
If this is ON, the looped waveform will play in synchronization with the
tempo or MIDI clock.
TM RATIO .............[BPM SYNC OFF: 000.5…400% (OVER)/BPM SYNC ON:
012.5…400% (OVER)]
This specifies the length of the looped waveform relative to the “DURA-
TION” value.
DURATION..................................................... [000…350ms, 1/64… 1/1]
Sets the duration of the grain.
The length of the waveform is determined by this setting and the “TimeRa-
tio” setting.
If “BPM SYNC” is OFF, this is set in msec units.
If “BPM SYNC” is ON, this is set as a timing resolution relative to the tempo
specified by the [TEMPO] knob or MIDI clock.
If the “DURATION” and “TM RATIO” settings exceed the limit, an
indication of
will appear for the “TM RATIO.”
LFO SYNC (LFO Tempo Sync) .......................................................[OFF, ON]
Specifies whether the LFO cycle will be synchronized with the tempo speci-
fied by the [TEMPO] knob or MIDI clock.
J p. 66 “LFO SYNC (LFO Tempo Sync)”
LFO FREQ (LFO Frequency) .........................................[0.01…100.0Hz]
In
Out
LFO Cycle /Duration
LFO Cycle
Duration
If “LFO SYNC” is Off, this specifies the cycle at which the waveform is
switched in Hz units.
The waveform length specified by “DURATION” will play as a loop, and the
waveform will switch at each cycle of the LFO.
If this parameter is assigned to “CTRL-1” or “CTRL-2,” switching
“BPM SYNC” On will change the assignment to “SYNC.NOTE.”
SYNC.NOTE (LFO Sync Note) ..............................................[8/1…1/64]
Sets the LFO frequency as a proportion of the tempo set by the [TEMPO]
knob.
NOTE
This parameter will be displayed and can be set if “LFO SYNC” is ON.
J p. 66 “SYNC.NOTE (LFO Sync Note)”
KEY SYNC (LFO KeySync).............................................................[OFF, ON]
Specifies whether the LFO will be reset by note-on.
J p. 67 “KEY SYNC (LFO KeySync)”
INI.PHASE (LFO Init Phase) .................................................. [000…180°]
Sets the starting location of the waveform.
NOTE
This parameter will be displayed and can be set if “KEY SYNC” is ON.
J p. 67 “INI.PHASE (LFO Init Phase)”
