Image formation process

Each of the following process function independently and must be coordinated with the other product

processes. Image formation consists of the following processes:

●

Latent-image formation block

◦

Step 1: primary charging

◦

Step 2: laser-beam exposure

●

Developing block

◦

Step 3: developing

●

Transfer block

◦

Step 4: transfer

◦

Step 5: separation

●

Fusing block

◦

Step 6: fusing

●

Drum cleaning block

◦

Step 7: drum cleaning

Figure 1-17 Image formation process

Drum cleaning

Developing

2. Laser-beam exposure

Fusing (Fixing)

6. Fusing (Fixing)

Delivery

7. Drum cleaning

3. Developing

1. Primary charging

Pickup

4. Transfer

5. Separation

Transfer

Latent image formation

: Media path

: Direction of drum rotation

: Block

: Step

ENWW Image-formation system 27
