8
26. Cues: This Pad Mode button switches the pads between two modes: Hot Cue Mode (red)
and Hot Cue Auto-Loop Mode (orange). When the button is unlit, the first press will always
select Hot Cue Mode.
• Hot Cue Mode: Each pad assigns a Hot
Cue Point or returns the track to that Hot
Cue Point. (Pads 1-5 are essentially
duplicates of Hot Cue Buttons 1-5).
When a Hot Cue Button is unlit, you can
assign a Hot Cue Point by pressing it at
the desired point in your track. Once it is
assigned, the Hot Cue Button will light.
Press and hold Shift and then press a
pad to delete its assigned Hot Cue Point.
• Hot Cue Auto-Loop Mode: Each pad
assigns a Hot Cue Point or returns the
track to that Hot Cue Point, but in both
cases, it also creates an Auto-Loop at
that point. The Auto-Loops length is set
in the software, but you can decrease or
increase it with the Parameter < or
Parameter > button.
27. Auto / Roll: This Pad Mode button puts the pads in two modes: Auto-Loop Mode (dark blue)
and Loop Roll Mode (light blue). When the button is unlit, the first press will always select
Auto-Loop Mode.
Note: The pad layouts here match the software's default Auto-Loop time division layout. If
you shift the range of time divisions displayed in the software, the pad layout will change to
match it.
• Auto-Loop Mode: Each pad triggers or
releases an Auto-Loop of a different
length. Press and hold Shift and then
press the Parameter < or Parameter >
button to shift the Auto-Loop backward
or forward.
• Loop Roll Mode: Each pad triggers a
momentary Loop Roll. Press the
Parameter < or Parameter > button to
change the Loop Roll's time division.
Hot Cue 1
Hot Cue 2
Hot Cue 3
Hot Cue 4
Hot Cue 5
Hot Cue 6
Hot Cue 7
Hot Cue 8
Hot Cue 1 +
Auto-Loop
Hot Cue 2 +
Auto-Loop
Hot Cue 3 +
Auto-Loop
Hot Cue 4 +
Auto-Loop
Hot Cue 5 +
Auto-Loop
Hot Cue 6 +
Auto-Loop
Hot Cue 7 +
Auto-Loop
Hot Cue 8 +
Auto-Loop
1/8-beat
Auto-Loop
1/4-beat
Auto-Loop
1/2-beat
Auto-Loop
1-beat
Auto-Loop
2-beat
Auto-Loop
4-beat
Auto-Loop
8-beat
Auto-Loop
16-beat
Auto-Loop
1/8-beat
Loop Roll
1/4-beat
Loop Roll
1/2-beat
Loop Roll
1-beat
Loop Roll
2-beat
Loop Roll
4-beat
Loop Roll
8-beat
Loop Roll
16-beat
Loop Roll
