provide DID digits. This field only displays if DIRECT INWARD DIALING is set to DISABLED.
DIAL PLAN (PKT VOICE) > NETWORK TERM > IFCE CONFIG > STRIP MSD
Write security: 3; Read security: 5
Strips a selected quantity (choose from NONE, 1, 2, and 3) of the most significant digits (MSD) of a dialed
number prior to being forwarded out of the port.
Example: A network port could be set to accept all calls beginning with 9 (9$), and then with
STRIP MSD
set to
1, all digits would be sent toward the network except the leading 9.
DIAL PLAN (PKT VOICE) > NETWORK TERM > IFCE CONFIG > SOURCE ID
Write security: 3; Read security: 5
Simplifies the creation of a dial plan in applications where the criterion for switching calls to a certain
endpoint is a function of which endpoint originated the call.
DEFAULT VALUE = 0. Zero is the default ID for all endpoints and accept numbers. With default values,
all calls are routed based only on the dialed number.
Multiple endpoints can have the same
SOURCE ID.
When creating the
CALL ACCEPT list, specify a SOURCE ID(s) as well as a dialed number or range of
dialed numbers to accept.
DIAL PLAN (PKT VOICE) > USER TERM
Write security: 3; Read security: 5
This menu allows the user to define option parameters for ports configured as user packet voice endpoints.
DIAL PLAN (PKT VOICE) > USER TERM > IFCE CONFIG
Write security: 3; Read security: 5
Specifies the configuration parameters for the endpoint.
DIAL PLAN (PKT VOICE) > USER TERM > IFCE CONFIG > DLCI
Write security: 3; Read security: 5
Selects the appropriate DLCI for this dial plan entry.
DIAL PLAN (PKT VOICE) > USER TERM > IFCE CONFIG > VOICE PORT
Write security: 3; Read security: 5
Identifies the voice port address of the remote unit. FSU 5622s support ports 1 and 2. A remote ATLAS
supports ports 1 through 255.
STRIP MSD does not affect CALL ACCEPT criteria. All of the digits (including the MSDs that
are subsequently stripped) are used as accept criterion.
