ATLAS 550 System Manual Section 4, User Interface Guide
61200305L1-1F © 2002 ADTRAN, Inc. 247
Legacy Data Option Module.
DEDICATED MAPS (PKT ENDPT - PACKET ENDPOINT)
DEDICATED MAPS (PKT ENDPT) > CREATE/EDIT MAPS > CONNECTS
Write security: 3; Read security: 5
To assign a packet endpoint to a physical port, select the port in the FROM SLOT/PORT field and configure
the
TO SLOT/PORT as follows:
DEDICATED MAPS (PKT ENDPT) > CREATE/EDIT MAPS > CONNECTS > TO SLOT/SERVICE
Write security: 3; Read security: 5
Select PKT ENDPNT to activate a list of available packet endpoints in the TO PORT field.
SYNC/ASYNC
Write security: 3; Read security: 5
Configures the port for either synchronous or asynchronous data transmission.
The mode of operation depends on the protocol selected in the PACKET MANAGER menus.
INTERFACE TYPE
Write security: 3; Read security: 5
Configures the physical interface of the port as EIA-232 or V.35. Selecting V.35 requires the NxT1
HSSI/V.35 Option Module (P/N 1200346L2) and the purchase of the option V.35 cables (P/N
1200348L1).
BIT RATE
Write security: 3; Read security: 5
Sets the interface bit rate for the port. Selections range from 2400 baud to 128 kbaud.
TD CLOCK SOURCE
Write security: 3; Read security: 5
Configures the interface to provide or recover data clocking.
This clock source is used ONLY on the Legacy Data Option Module and cannot be used as
a source for system timing.
TRANSMIT IDLE CODE
Write security: 3; Read security: 5
Configures the port to use Flags or Ones as the idle code.
