Installation 9
3
89VP Instruction Manual Section 2: Installation
PN 51-389VP January 2013
FIGURE 2-3. Flow Through and Insertion Installations
FIGURE 2-4. VP8 Cable, sensor end
1-1/2” x 1”
Reducing
Bushing
1-1/2” x 1”
Reducing
Bushing
1-1/2” x 1”
Reducing
Bushing
#$
1-1/2” Pipe Tee
1-1/2” Pipe Tee
1-1/2” Pipe “Y”
Valves and fittings by others. Mount the sensor at least 10° from horizontal.
FIGURE 2-5. VP8 Cable, instrument end
