Preparing for Cross-OS File Exchange Operations 3-5
Hitachi USP V Cross-OS File Exchange User’s Guide
When you use MTO and OTM for the dataset allocated by VSE2.3, you must
specify RF (Record Format), RL(Record Length) and BL(Block Length) by using
the correct VSE parameters.
When you use MTO and OTM for the dataset allocated by VSE2.5, FX can
transfer data without a VSE parameter.
Table 3-2 Support Matrix for VSE OS, VSE Parameter and Record Format
Record Format OS andFX Version
VSE Parameter
F FB V VB
Yes
VSE2.3 and previous
(FX: 01-xx-58 and
previous)
No
× × × ×
Yes
Note 1
Note 2
VSE2.5 and higher
(FX: 01-03-59)
No
Note 3
Note 4
Key:
o: Transfer is available
×: Transfer is not available
F: Fixed non-block length
FB: Fixed block length
V: Variable non-block length
VB: Variable block length
Note 1: It is possible to transfer data between correct dataset
attribute(5≦RL≦BL-4). The data transfer is valid only if the VSE parameters
are as shown:
RL≦32756
BL≦32760
BL=RL+4
For the following dataset attributes, the data transfer is invalid if user does
not specify the VSE parameter value as shown above.
RL＞32756
BL＞32760
For the following dataset attributes, the data transfer is invalid if user does
not specify the VSE parameter value between RL and BL values shown in #1
and #2.
RL≦32756
BL≦32760
RL=BL
