7-4 Troubleshooting
Hitachi USP V Cross-OS File Exchange User’s Guide
Error
Code
Error Message and Description
Recommended Action(s)
-16 DATASET_ERROR_DATASET_NOT_CLOSED
An attempt was made to open the dataset without
closing it first.
Make sure the requirements and restrictions
specified in Chapter 6 are met. For example:
Dataset open and close must be used as a pair.
More than one dataset cannot be open within one process.
datasetOpen, datasetGetFileInformation, and
datasetFindFirstFile cannot be used while the dataset is
being accessed by datasetGetFileInformation or
datasetFindFirstFile.
datasetGetFileInformation and datasetFindFirstFile cannot
be used while the dataset is being accessed datasetOpen.
-17 DATASET_ERROR_BUFLEN_SHORT
The buffer length specified by datasetGet is shorter
than the actual record length.
Make sure that the buffer area is larger than the
dataset record length.
-18* DATASET_ERROR_VOLUME_LABEL_INVALID
No standard volume label was found, or the contents
of the VTOC are illegal.
Make sure that volume initialization is complete
and correct on the z/OS host. This error occurs
when a system that does not support large files
accesses a formatted volume from a system that
supports large files. This error also occurs when a
data partition size is incorrect for Solaris.
-19* DATASET_ERROR_VTOC_INVALID
No VTOC found, or contents of VTOC are invalid.
Make sure that the VTOC was created correctly
on the z/OS host.
-20* DATASET_ERROR_VOLUME_NOT_DEFINED
The specified volume is not defined.
Make sure that the specified volume has been
entered correctly in the FX volume definition file.
-21 DATASET_ERROR_INVALID_ARGUMENT
An argument of the function is invalid.
Make sure that the argument for the FAL
function is correct.
-22 DATASET_ERROR_NO_DATASET
No dataset was found.
Make sure that the dataset has been created
correctly on the z/OS host.
-23* DATASET_ERROR_NON_STANDARD_R0_EXIST
Nonstandard record 0 (R0) exists.
Change the R0 track format to standard track
format. FAL cannot write on tracks with
nonstandard R0.
-24 DATASET_ERROR_INVALID_MODE
The mode argument of datasetOpen is not valid.
Make sure that the value of the mode argument
for the datasetOpen function is either r (for
read) or w (for write).
-25* DATASET_ERROR_VOLUME_DEFINED_READ_ONLY
The open-system host tried to write to a read-only
volume.
Make sure that the target dataset for an open-
system write operation is on a 3390-3A/C
volume.
-26 FAL_INTERNAL_ERROR
Internal error of FAL
Collect error logs file and error dump file. And
make contact a maintenance staff. This error
occurs when the open system does not have
enough memory.
-27* DATASET_ERROR_END_OF_VOLUME
The end of volume was detected before the end of
dataset was detected.
The open-system volume/partition size is smaller
than the z/OS volume size. Make sure that the
partition size is specified correctly on the open
system. This error occurs when the open system
disk is full or it exceeds a limitation for FXmto.
-28 DATASET_ERROR_OVERFLOW
Data cannot be written because the dataset is full.
Check the size of the data to be written, and
extend the size of the dataset as needed.
