“Dual Equipment - Separate Heaters” for Pool/Spa configuration
These systems have 2 complete sets of equipment (filter pump, filter, heater)—1 set for the pool and the
other set for the spa. Refer to the diagram below:
Some important notes regarding the Aqua Logic control of Dual Equipment Pool/Spa systems with separate
heaters:
In the Pool/Spa Config., select:
Pool and Spa-Dual
Heaters
1. When dual equipment is selected:
a. The “Filter” pump automatically is renamed “Pool Filter” and can not be changed. The
pool filter can be a one or two speed pump.
b. The “Aux1” output is automatically renamed “Spa Filter”, its function is set to “Timeclock”
and the Interlock feature is forced to “Disabled”. None of these can be changed. The spa
filter can be a one or two speed pump.
c. The Heater1 output should be connected to the spa heater—the heater will only turn on
when the spa filter pump is running.
d. The Heater2 output should be connected to the pool heater—the heater will only operate
when the pool filter is running. If the system does not have a pool heater, disable Heater2
in the configuration menu and then the relay can be used to operate general purpose
Valve4.
2. The water sensor should be installed on the pool loop prior to the heater and will display the pool
temperature whenever the “Pool Filter” pump is running.
10
FILTER
HEATER
HEATER
BYPASS
VALVE
(manual)
HEATER
BYPASS
VALVE
(manual)
POOL SWEEP
BOOST PUMP
WATER
FEATURE
POOL/SPA
SPILLOVER
VALVE
WATER
FEATURE
VALVE
SPA
SPA JET
PUMP
SPA
BLOWER
POOL VACUUM
VALVE
MANUAL
VALVE
ENERGY
FILTER
TWO-WAY
VALVE
SKIM
POP-UP
SPILLOVER
POP-UP
OVERFLOW
POP-UP
RETURN
JET
IN-FLOOR
CLEANER
VALVE
WATER
FEATURE
PUMP
WATER
FEATURE
POP-UP
MAIN
DRAIN
ENERGY
SAVER
PRESSURE
CLEANER
NON-BOOST
PRESSURE
CLEANER
PRESSURE
CLEANER
SUCTION
CLEANER
POOL
High Voltage Relays Valve Outputs
Heater Outputs
Pool Filter Pump
Lights
Spa Filter Pump (Aux 1)
Aux 2 - Aux 6
Pool/Spa Spillover
Valve 3
Valve 4
TRANSFORMER
HIGH VOLTAGE
LIGHTS
LOW VOLTAGE
LIGHTS
FIBER OPTIC
LIGHT SOURCE
COLOR WHEEL
ISOLATED
WATER
FEATURE
PUMP
POOL
TEMPERATURE
SENSOR
SPA
TEMPERATURE
SENSOR
FILTER
HEATER
CELL
FLOW
SWITCH
MANUAL
VALVE
POOL FILTER
PUMP
SPA FILTER
PUMP
CHECK
ALVE
(prevents draining
(adjust cams as necessary
for proper spillover)
Heater 1 (Spa)
Heater 2 (Pool)
29
If solar is “Enabled”, the valve or solar pump relay will turn on when the water temperature is
less than the desired temperature setting AND the solar sensor is hotter than the water by at
least 8ºF. The desired temperature is in the “Settings Menu”. If applicable, the homeowner
will be prompted to enter separate pool and spa desired temperature settings. Depending on
the position of the pool/spa suction valve, the proper temperature setting will be used.
Solar Extend
If “Enabled”, the filter extend logic keeps the filter pump running beyond the normal turn-off
time if solar heat is still available. When solar heat is no longer available, both the solar
valve/pump and filter pump will turn off simultaneously. Solar extend will NOT cause the
filter pump to turn on, it will only delay the turn off time when solar is operating.
Solar Priority
If both “Solar Control” and “Heater Control” are enabled, the Solar Priority feature will keep
the conventional heater off whenever solar heat is available. This provides the most cost
effective way of heating the pool. When solar heat is not available, the conventional heater
will operate normally.
Lights Config.
+ to view/change
Lights Function
Manual On/Off
Lights Name
Pool Light
Lights Relay
Standard
Push to access Lights options
Rotates between
Manual On/Off (default), Countdown Timer, Low Speed-
Filter, Timeclock, Solar, Low speed-Spa Filter, Group, and Super Chlorinate
Rotates between all available names
Toggle between Standard (default) and Dimmer
Move to previous/next configuration menu
Move to next menu item
Move to next menu item
Move to next menu item or previous/next configuration menu
Lights Interlock
Disable
Lights Freeze
Disable
Toggle between Enabled and Disabled (default) Lights Interlock
Toggle between Enabled and Disabled (default) Lights Freeze
Move to next menu item
Move to previous/next configuration menu
+
+
+
+
+
+
>
>
>
>
>
>
>
>
>
>
>
>
for all functions except solar, dimmer relay,
low speed (filter pump), and group
for all functions except dimmer relay,
low speed, and group
for manual on/off, countdown
timer and timeclock functions
Lights Group
Filter: Unaffected
Lights Group
Timer: None(Manual)
Options available depend on the function that is selected
Rotates between Manual On/Off (default),Countdown Timer and Timeclock
Move to previous/next menu item or next configuration menu
Move to next menu item
+
+
>
>
>
>
for group function only
for group function only
Lights Name
The Aqua Logic allows you to assign any one of a number of names (e.g. “Pool Light, Spa
Light, Deck Light, etc.) to this control function. Note that other lights may be assigned to
other Aux outputs. This will make the Aqua Logic much more user friendly to the homeowner
when they want to turn various lights on or off. A sheet of small name labels is included with
the Aqua Logic main unit and each remote display/keypad so that the “Lights” pushbutton
can be labeled the same as the name that you have assigned. At this time it is also a good
idea to make sure that the relay in the control box is also labeled (hand written) with the same
name as a help to technicians who may service this system at a later date.
