Pin Assignment
Satellite U400/Satellite Pro U400/PORTEGE M800 Maintenance Manual 31
23 PCIE_RXN3 I 24 NC ---
25 PCIE_RXP3 I 26 GND ---
27 GND --- 28 +1.5V ---
29 GND --- 30 NC ---
31 PCIE_TXN3 O 32 NC ---
33 PCIE_TXP3 O 34 GND ---
35 GND --- 36 Test point ---
37 NC --- 38 Test point ---
39 NC --- 40 GND ---
41 NC --- 42 NC ---
43 NC --- 44 NC ---
45 PCLK__debug I 46 NC ---
47 PLTRST#_debug I 48 +1.5V ---
49 LDRQ#1__debug O 50 GND ---
51 SERIRQ_debug O 52 +3V ---
CN35 Internal MINI card slot
P/N:DFHS52FR016 CONN DIP HOUSING 52P 2R FR(P0.8,H6.5)
PIN No. Signal name I/O PIN No. Signal name I/O
1 WLAN_WAKE# O 2 +3V ---
3 WCS_DATR I/O 4 GND ---
