Basic Operations 6-43

Basic Operations

Using the Multi-Sheet Bypass Tray (continued)

Load offset tabbed sheets so that the tab extensions are on the right at the rear (not

front) of the tray. The top sheet is designated face up as the first tab of the finished set.

Subsequent offset tab sheets follow in sequence.

When loading tabbed sheets in the Multi-sheet bypass tray, be sure to specify the paper

type as TAB on the Paper Type/Size Setting Screen; otherwise mishandled paper may

occur. See p. 6-19 to p. 6-21.

Section 1

Introducttion

3rd TABS

2nd TABS

1st TABS

3 FINISHED SETS

ONE FINISHED SET

Example: 9 Tabbed sheets loaded in position for 3 finished sets.

Example: 3 Tabbed sheets loaded in position for one finished set.

Section 1

Introduction

3rd TAB

2nd TAB

1st TAB

Printed

side

Printed

side

Section 1

Introduction

Section 1

Introduction

Section 1

Introduction

1st TAB

2nd TAB

3rd TAB

2nd TAB

3rd TAB

Section 1

Introduction

1st TAB

Rear

Front

Rear

Front
