Setting Up the Printer
To set up a parallel printer for use with the system:
1 Log on to the system as root.
2 Enter cd /etc/uucp
3 Edit the Systems file to add an entry for the printer. This entry must
include the hex representation for the printer IP address and port.
hp4si Any hplaser - \x002<hex value for port><hex value for IP
address>
For example, hp4si Any hplaser - \x0002238cc776928 uses 238c as the
hex representation for port 9100 and c7769828 as the hex representation
for IP address 199.118.152.40.
4 Edit the Devices file with the following line:
hp4si tcp - - TLI \D
5 Save and exit the Devices file.
6 Enter
lpsystem -tbsd -Tnever -R0 -y”printer_name IP_address” hp4si
where printer_name and IP_address are appropriate for the printer you
are adding.
7 Enter lpadmin -php4si -Uhp4si -Ipcl -Thplaserjet
