6 Peripheral Administration Modem Administration
UCS 1000 R4.2 Administration 585-313-507 Issue 3 April 2000 260
7 Press F1 (Next) to display Async DTE Rate.
8 Press or to display the baud.
9 Press F2 (Select).
The LCD displays the baud.
10 Continue with the next procedure, Setting the DTR Action and DSR
Control to Standard RS-232 on the Modem on page 260. Do not return to
the top-level menu.
Setting the DTR Action and DSR Control to Standard RS-232 on the Modem
To set the DTR action to standard RS-232 on the modem:
1 Press F1 (Next), more than once if necessary, to display DTR Action.
2 Press or to display Stndrd_RS-232.
3 Press F2 (Select).
4 Press F1 (Next) to display DSR Control.
5 Press or to display Stndrd_RS-232.
6 Press F2 (Select).
