Intelligent Technologies (
IT.
) D77B-DSNAP
Pub. No. MN05004001E
41
September 2002
Table 47: Assembly 105 (0x69) — D77B-DSNAP Abbreviated Motor Starter 1
Table 48: Assembly 106 (0x6A) — D77B-DSNAP Abbreviated Motor Starter 2
Table 49: Assembly 108 (0x6C) — D77B-DSNAP Motor Starter with Fault Code
Table 50: Assembly 109 (0x6D) — D77B-DSNAP Expanded Motor Starter with Fault Code
Table 51: Assembly 114 (0x72) — D77B-DSNAP Complete Status Assembly
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 At Reference Reserved CtrlFrom Net Ready Reserved Running1 Warn Fault
1 % Thermal Capacity
2 % FLA
3 Fault Code (Low byte only)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 At Reference Reserved CtrlFrom
Net
Ready Running2 Running1 Warn Fault
1 % Thermal Capacity
2 % FLA
3 Last Fault Code (Low byte only)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 At Reference Reserved CtrlFrom
Net
Ready Reserved Running1 Warn Fault
1 % Thermal Capacity
2 Average Current (Low byte)
3 Average Current (High byte)
4 Last Fault Code (Low byte)
5 Last Fault Code (High byte)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 At Reference Reserved CtrlFrom
Net
Ready Running2 Running1 Warn Fault
1 % Thermal Capacity
2 Average Current (Low byte)
3 Average Current (High byte)
4 Last Fault Code (Low byte)
5 Last Fault Code (High byte)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 At Reference Reserved Ctrl From
Net
Ready Running2 Running1 Warning Fault
