Chapter 10. Dedicated Maps
61200305L1-1 ATLAS 550 User Manual 10-5
DS0
S
A
VAILABLE
Read security: 5
Indicates which DS0s of the T1 are assigned. DS0 assignment is based on
the following items:
T1 T
ROUBLE
C
ODE
S
ERVICE
Write security: 3; Read security: 5
Sets known values in the data field for outgoing DS0s which are cross-con-
nected to a T1 port experiencing alarms. Choose from O
FF
, V
OICE
, D
ATA
,
and C
USTOM
,dependingonthetypeoftrafficontheT1.
T1 T
RUNK
C
ONDITIONING
S
ERVICE
Write security: 3; Read security: 5
Sets known values in the signaling bits and the data field for outgoing DS0s
which are cross-connected to a T1 port experiencing alarms. The trunk con-
ditioning process consists of a 2.5-second transmission (indicating call ter-
mination), followed by a continuous transmission signaling the final
condition as chosen by the user. See the trunk conditioning example on
page 10-7.
Choose from O
FF
, V
OICE
E&M, V
OICE
LS/GS U
SER
T
ERMINATION
, V
OICE
LS/
GS N
ETWORK
T
ERMINATION
, D
ATA
SW56,andC
USTOM
—depending on the
type of traffic or configuration of the T1.
0-9 This DS0 is available. The digit that displays in this field represents
thelastdigitoftheDS0number.
* This port is requesting this DS0 for this connection, but the DS0 is
not yet activated.
! This DS0 is used by this port in this connection and is activated.
S
This DS0 is used in the switched Dial Plan.
S This DS0 is used in the switched Dial Plan and conflicts with this
connection.
N
This DS0 is already used in this dedicated map.
N This DS0 is already used in this dedicated map and conflicts with
this connection.
T1 Trouble Code Service only applies to non-RBS T1s in the
D
EDICATED
M
AP
.
Trunk conditioning only applies to RBS T1s in the dedicated map.
