6
D
Cartridge
Drawer
UK Helpline 0844 871 0953 Replacement Parts 0844 873 0719 Ireland Helpline 1800 409 119
7 Press the steam button ⁄ for steam
ironing.
8 Depress the power switch Á to turn
off the base unit when ironing is
complete.
MODELS WITH
SPRAY FEATURE
Certain models are fitted with a
spray feature. Stubborn creases and
excessively dry clothing can be
softened by damping the material
with water. This procedure means
ironing can be achieved without
applying excessive pressure.
Filling
C
To fill the tank with water, press the
release button Ô and lift away the
spray unit Ì.
Pull the tank away from the spray
unit in a downward direction, taking
care not to damage the tank, and fill
water to the ‘Full’ mark.
Re-assembly
C
Attach the tank to the spray unit,
taking care to align the parts
correctly.
Locate the spray unit to the front of
the iron and press it home until the
unit locks into place.
Press the pump Ó a few times to
purge the air from the system, when
a fine mist of water is created, the
unit is ready for use.
Dry ironing
1 Connect the appliance to a suitable
mains outlet.
2 Press the steam switch Î 2 times
until all three steam level indicator
lights go off (steam off mode).
3 Turn the temperature dial › on the
iron in a clockwise direction, select
dot-1, dot-2, or dot-3 according to
the recommendation of the garment
label.
4 The temperature indicator light ¤
glows on the iron, indicating that it is
switched on.
5 When the required temperature is
reached, the temperature indicator
light on the iron goes off. The iron is
ready to use.
It is always a good idea to begin with
‘cool’ fabrics and work up to higher
settings.
An iron heats up quicker than it
cools down so you’ll save time and
electricity.
Auto-shut off
(Certain models only)
An auto-shut off system will activate
if the steam is not used for over 15
minutes. The mains indicator light Á
will flash between green and red
indicating the unit is in ‘sleep mode’.
When this occurs, press the steam
select button Î or the power switch
Á ‘ON’ once. The appliance will
switch on immediately and you need
to check, and select, the required
setting.
ANTI-SCALE SYSTEM
The anti-scale cartridge is designed
to reduce the build-up of limescale
which occurs during steam ironing.
This will prolong the working life of
your iron. However, please note that
the anti-scale cartridge will not
completely stop the natural process
of limescale build-up.
When the cartridge needs replacing,
the indicator light  will flash.
NOTE: The unit will not switch off,
but you need to replace the cartridge
as soon as possible.
Replacing anti-scale
medium D
1 When the indicator light  flashes,
you need to replace the anti-scale
cartridge Ë.
2 The steam generator needs to be
connected to the mains supply.
C
Ó
Ô
Ì
