COMPONENTS OF YOUR STEAM GENERATOR
UK Helpline 0844 871 0953 Replacement Parts 0844 873 0719 Ireland Helpline 1800 409 119
42286 42287 42288 42296 42297 42298 42299 42301 42302 42303
Iron unit
⁄ Steam trigger
¤ Temperature indicator light
‹ Soleplate
› Temperature control knob
fi Supply cord from base unit
Base unit
fl Supply cord
‡ Mains cable
· Water tank
· Illuminated water tank
‚ Water tank filler
„ Tank release knob
‰ Mains cable clip (storage)
 Replace anti-scale cartridge indicator
Ê ‘Fill’ water tank indicator
Á On/off button plus steam ready indicator
Á On/off button plus steam ready and
auto-shut off indicator
Ë Anti-scale cartridge (behind water tank)
È Supply cord storage clip
Í Steam level indicator lights (variable)
Î Steam level selection button (variable)
Ï Mains cable storage
Water spray unit
Ì Spray unit
Ó Spray button
Ô Spray cover release button
Spray bottle (internal)
È
