– 45 –
1 37440400 FRAME ASSY TMP2 1
2 33910070 PAPER GUIDE A TMP2 1
3 33900050 SUB-GUIDE TMP2 2 TSP212/242
4 33210020 HOLDER ROLLER TMP2 1
5 30365020 HOLDER ROLLER SHAFT TMP2 1
6 37447000 DETECTOR UNIT TMP2 1 S
7 32025030 SET COVER TMP2 1
8 31360000 STAY TMP2 1
9 30375010 PLATEN TMP2 1 S
10 33490020 HEAD-UP LEVER TMP2 1
11 04310403 OILESS BUSHING F4X6X5 2 S
12 33910080 PAPER GUIDE B TMP2 1 TSP212/212-24
13 32490020 HEAD OPEN LEVER TMP2 2 S
14 33020300 MOTOR COVER TMP2 1
15 33101510 PLATEN GEAR TMP2 1 S
16 33990000 PLATEN KNOB TMP2 1 S
17 30905021 THERMAL HEAD M22E 1 TSP212-24/242-24 S
30905030 THERMAL HEAD RJ072-8S63 1 TSP212/242 S
18 33102230 GEAR 20X43X0.35 TMP2 1 S
19 33102220 GEAR 13X44X0.35 TMP2 1 S
20 32042030 HEAD PLATE TMP2 1
21 37442400 MOTOR ASSY TMP2 1 S
22 04020002 STOP RING SE1.5 1 S
23 04020010 STOP RING SE2.0 3 S
24 04020004 STOP RING SE2.5 2 S
25 01901709 SCREW TAT 1.7-5 CT FL 1 S
26 00820304 SCREW TR 2-3 2 S
27 00626404 SCREW TR 2.6-4 2 S
28 30510300 SPRING E032-035-0109 2 S
29 30520040 SPRING C048-054-0110 3 S
30 82500860 WAVE WASHER 834G 1
DRWG.NO. REV. PARTS NO. PARTS NAME Q’TY REMARKS RANK
2-2. Parts List
Printer Mechanism
