PARAMETER SUMMARY
The following tables show the ATV58 TRX Type H configuration parameters. This page can be copied
and used as a worksheet to customize settings for your application.
Adjustment Parameters
Code Fact. Setting Cust. Setting Code Fact. Setting Cust. Setting
ACb no SP6 30 Hz Hz
ACC 3 s s SP7 35 Hz Hz
dEc 3 s s JOG 10 Hz Hz
LSP 0 Hz Hz JGt 0.5 s s
HSP 50 / 60 Hz Hz brL 0 Hz Hz
FLG 20% % Ibr 0 A A
StA 20% % brt 0 s s
ItH 0.9 of I
n
A bEn 0 Hz Hz
IdC 0.7 ItH A bEt 0 s s
tdC 0.5 s s FFt 50/60 Hz Hz
SdC Varies A rPG 1
JPF 0 Hz Hz rIG 1 / s / s
JF2 0 Hz Hz PSP 0.0 s s
JF3 0 Hz Hz FbS 0.1
AC2 5 s s PIC no
dE2 5 s s PI2 30% %
tLS no no or s PI3 60% %
USC 1 dtd 105% %
UFr 100% % dtS 1
SLP 100% % Ctd 1.36 of I
n
A
PFL 20% % ttd 100% %
SP2 10 Hz Hz tL2 200% %
SP3 15 Hz Hz Ftd 50/60 Hz Hz
SP4 20 Hz Hz F2d 50/60 Hz Hz
SP5 25 Hz Hz
Drive Menu Parameters
Code Factory Setting Customer Setting Code Factory Setting Customer Setting
UnS depends on catalog number V Stt STN
FrS 50 / 60 Hz Hz dCF 4
nCr 0.9 of I
n
A tLI 200% %
nSP depends on catalog number rpm CLI 1.3 6 of I
n
COS depends on catalog number AdC yes
tUn no PCC 1
tFr 60 / 72 Hz Hz SFt LF
nLd no SFr depends on catalog number kHz
Fdb no nrd yes
Frt 0 Hz Hz SPC no
rPt LIN PGt DET
brA no PLS 1024
Command Menu Parameters
Code Factory Setting Customer Setting Code Factory Setting Customer Setting
tCC 2 W AOH 20 mA mA
tCt LEL Str no
rln no LCC no
bSP no PSt yes
CrL 4 mA mA Add 0
CrH 20 mA mA tbr 19200
AOL 0 mA mA rPr no
