Operating Instructions
54
• Set up the IPsec policy as shown below.
9. Access this product (see page 12).
• If you can access this product, the IPsec setup is complete.
Notes
• In IPsec communications, "IPsec" is displayed on the Top page or the
Single Camera page.
• If you cannot communicate using IPsec, see page 20 of the
Troubleshooting on the Setup CD-ROM.
• See the Panasonic support website at
http://panasonic.co.jp/pcc/products/en/netwkcam/ for the IPsec
features.
Phase 2 Mode Quick mode
PFS Specifies either of Off, D-H Group 1 or D-
H Group 2.
Cipher Algorithm Select from DES-CBC, 3DES-CBC,
AES-CBC (128, 192, 256 bits) or NULL.
(Multiple selections are available.)
Message-Digest
Algorithm
HMAC-MD5-96, HMAC-SHA-1-96
(Multiple selections are available.)
Lifetime Specifies by 28800 s (Byte setting is not
supported.)
*1
This product does not support aggressive mode.
Items Settings
Protocol ANY
Source Network Network address and subnet mask on the LAN side of the
VPN router
Source IP address A global address on the WAN side of the VPN router
Destination Network A global address of camera server
Destination IP address A global address of camera server
IKE Items Settings
