Operating Instructions
[For assistance, please call: 1-800-272-7033] 47
Tunnel Mode (IPv4/IPv6)
An IPsec mode of operation where the entire IP packet including IP header is
authenticated and encrypted. A new IP header is added (protecting the entire
original packet). Both VPN clients and VPN gateways can use this mode.
Note
This product can be accessed only from the PCs under the VPN router. Other
PCs cannot access this product.
Prepare the following requirements.
Item Supported Feature
PC Operating System : Windows XP, Windows 2000, Windows
Me, Windows 98SE (in IPv4)
: Windows XP Service Pack 1 or later (in
IPv6)
Web Browser : Internet Explorer 6.0 or later
Router ISP Service
(in IPv4)
: Static global address service (A global
address must be set up to the WAN side
of the router.)
ISP Service
(in IPv6)
: "IPv4/IPv6 Dual-Stack" or "IPv6 over
IPv4 Tunneling" service
Note
See the Panasonic support website at http://
panasonic.co.jp/pcc/products/en/netwkcam/ for the
recommended router.
Camera Server ISP Service
(in IPv4)
: Services for multiple static global
addresses (A global address must be
set up to this product.)
ISP Service
(in IPv6)
: "IPv4/IPv6 Dual-Stack" or "IPv6 over
IPv4 Tunneling" service
