MAXIMUM CAPACITIES AND LOADING TIPS
MODEL 220
40
14
14
14
14
14
14
14
14
14
14
14
Max 4" dia.
bottles
Max 3.5" dia.
bottles
3 rows 3" dia.
or
2 rows 4.5" dia.
Max: 220 3" bottles
26
MODEL 110
20
7
7
7
7
7
7
7
7
7
7
7
Max 4" dia.
bottles
Max 3.5" dia.
bottles
3 rows 3" dia.
or
2 rows 4.5" dia.
Max: 110 3" bottles
13
Maximum capacities and sample loading arrangements for Vintage Keeper Odyssey wine cellars
are illustrated below. Note the variations in shelf height, to accomodate the widest variety of
bottle types and sizes. Standard Burgundy and Bordeaux bottles are best arranged with necks
facing out; some taller bottles may need to be arranged neck to neck. Never stack bottles more
than two rows high on a shelf; all shelves must be installed as directed. Avoid placing bottles
directly in front of the cooling unit’s circulating fan.
