Fuser Kit - Replacing the Fuser
Ordering and Replacing Consumables 4-29
Consumables
Fuser Kit - Replacing the Fuser
The fuser is replaced when the Control Panel indicates:
Fuser At End Life
Replace Fuser
This section provides maintenance procedures for removing the old fuser and installing the
new one.
Note This procedure is applicable to both 120-127 VAC and 200-240 VAC fusers.
1. Press the Menu button on Main Screen.
2. Press
Ĭ to highlight Maintenance.
3. Press
Ǡ to display Maintenance selections.
4. Press
Ǡ to display replace selections
5. Press
Ĭ to select fuser.
6. Press Select to display fuser instructions, as shown in Figure 4-33.
Figure 4-33 Fuser instructions
Online
Fuser unit Replacement
Replace Fuser unit and
Press Done
Done
