Chapter 6 Call Commands
Call Command Behavior
DIALING: User is entering phone
number, which is parsed with the given
dial-plan rules
• R—Abort dialing, restart dial tone, and revert to PREDIAL state.
• Invalid phone number—Abort dialing, plays fast-busy, and go to
WAITHOOK state.
CONFIG: User configuring a
supplementary service in the United
States
• *69—Call Return
• #72v#—Forward unconditional to number specified in 'v'l (PacBell use 72#).
• #73—Cancel any call forwarding (PacBell use 73#).
• #74v#—Forward on busy to number specified in 'v' (PacBell does not enable
this service from the phone).
• #75v#—Forward on no answer to number specified in 'v' (Pac Bell does not
enable this service from the phone).
• *67—CLIR in the next call (if global profile is CLIP)
• *82—CLIP for the next call (if global user profile is CLIR)
• *70—Disable call waiting in the next call.
• *99—Enable Fax Mode in the next call (non-standard).
• Dial-tone—Revert to PREDIAL state.
• Any complete configuration sequence—Carry out the configuration
command, restart dial-tone, and revert to PREDIAL state.
CONFIG: User configuring a
supplementary service in Sweden
• *21*v#—Forward unconditionally to number specified in 'v'.
• *67*v#—Forward on busy to number specified in 'v'.
• *61*v#—Forward on no answer to number specified in 'v'.
• #21#—Cancel any call forwarding.
• #67#—Cancel any call forwarding.
• #61#—Cancel any call forwarding.
• #31#—CLIR in the next call.
• *31#—CLIR in the next call.
• *43#—Enable call waiting in the next call (Sweden allows globally disable
call waiting).
• #43#—Disable call waiting in the next call.
• *69#—Call Return
• (non-standard)*99#—Enable Fax Mode in the next call (non-standard).
All Regions:
• R or any unrecognized sequence—Abort configuration, restart dial tone and
revert to PREDIAL state.
• Any complete configuration sequence—Carry out the configuration
command, restart dial tone, and revert to PREDIAL state.
CALLING: Phone number is sent;
Cisco ATA is waiting for response from
the far end
• R—Cancel the outgoing call, restarts dial-tone, and revert to PREDIAL
state.
Table 6-4 Call Command Behavior (continued)
Cisco ATA State and its Definition Summary of Commands (Input Sequence and Actions)
