Chapter 6 Call Commands
Call Command Behavior
Call Command Behavior
Table 6-4 summarizes differing Call Command behavior based on the U.S. and Sweden default call
commands.
U.S. Call Command Default
Af;AH;BS;NA;CS;NA;Df;EB;Ff;EP;Kf;EFh;HQ;Jf;AFh;HQ;I*67;gA*82;fA#90v#;OI;H#72v#;bA#74
v#;cA#75v#;dA#73;eA*67;gA*82;fA*70;iA*69;DA*99;xA;Uh;GQ;Af;AH;
Sweden Call Command Default
BS;NA;CS;NA;Df;EB;Ff0;ARf1;HPf2;EPf3;AP;Kf1;HFf2;EFf3;AFf4;HQ;Jf1;HFf2;EFf3;AFf4;HQ;A
f4;HQ;I*31#;gA#31#;gA*90*v#;OI;H*21*v#;bA*61*v#;dA*67*v#;cA#21#;eA#61#;eA#67#;eA*31#
;gA#31#;gA*43#;hA#43#;iA*69#;DA*99#;xA;Uh;GQ;
Table Notations
The following notations are used in Table 6-4:
• FE—Far end
• AFE—Active Far End, which is a connected far end that is not placed on hold
• WFE—Waiting Far End, which is a connected far end being placed on hold, or an incoming caller
waiting to be answered
• R—Hook Flash
• ONH—On Hook
• OFH—Off Hook
• 0-9,*,#—DTMF digits
• v—a variable length string, usually a phone number, and does not include #
• CWT—call-waiting tone
Note The notations in Table 6-4 include abbreviations for input sequence behavior. Refer to the tables and
syntax examples shown earlier in this section. The Summary of Commands column in Table 6-4 is based
on the actual command syntax used in the default Call Command strings for the United States and
Sweden.
Table 6-4 Call Command Behavior
Cisco ATA State and its Definition Summary of Commands (Input Sequence and Actions)
IDLE: Phone is on-hook; Cisco ATA is
waiting for incoming call
• OFH—Start dial tone and go to PREDIAL state.
• New incoming call or a waiting call (started before it enters IDLE)—Start
ringing the phone and go to the RINGING state.
PREDIAL: Phone just went off-hook but
no DTMF has been entered yet;
Cisco ATA plays dial-tone
United States and Sweden:
• # , *—Stop dial-tone, go to the CONFIG state, and prepare to accept a
complete configuration sequence.
• 0-9: Stop dial tone, start invoking dial-plan rules, and go to the DIALING
state to accept a complete phone number.
