Page 4 For technical questions, please call 1-800-444-3353. SKU 42619
Turn the plane’s switch off. The 4.
OFF position is the position closer
to the Battery. Plug the Charger into
the Charging hole on the Fuselage.
Charging takes about 30 seconds. The
NiMH battery in the plane is fully charged
when it becomes warm to the touch.
Test the charge by touching the battery
with your nger.
WARNING! DO NOT CHARGE THE
BATTERY LONGER THAN 30
SECONDS. Allow the battery to
cool down after each charging.
Overcharging can cause overheating,
resulting in PERSONAL INJURY or
property damage.
OPERATION
Choose a day when the wind is light. 1.
Find a wide-open eld.
NOTE: Keep an eye on your Airplane to
avoid losing it. For this reason, a large
area free of obstructions and debris is
ideal for ying your Airplane.
Turn the Switch ON. Gently toss the 2.
Airplane into the wind with the Nose
pointing slightly upward. Keep the
Wings level. The Airplane will slowly
begin climbing.
The airplane will y in a circle, in a radius 3.
of about 24 to 30 Feet. If the ying
radius is too big or if the Airplane is ying
straight, you can adjust its pattern for the
next ight.
After being fully charged, the airplane will 4.
y for a period greater than one minute,
and will climb to about 50 feet altitude.
To adjust the pattern, bend the rudder 5.
slightly left or right. If the head of the
plane appears too heavy, you can correct
this by slightly bending the Horizontal
Stabilizer upward or downward.
Turn the airplane’s switch off after use.6.
MAINTENANCE
Let the battery cool down between ights 1.
to maximize performance.
Do not use polystyrene cement for 2.
repairs, as it may melt parts of the plane.
If the Propeller Shaft has been pushed 3.
into the Body after a collision, you can
simply pull the Shaft out. Make certain
that the power is OFF before you do so.
Let the battery run out before each 4.
charge to prolong battery life.
Remove batteries if the Airplane is not 5.
used for a long period of time.
PARTS LIST
Part Description
RZ - FF2 - 1 Wing & Stabilizer
RZ - FF2 - 2 Battery
RZ - FF2 - 3 Portable Charger
RZ - FF2 - 5 Propeller / Spinner
RZ - FF2 - 6 Landing Gear
RZ - FF2 - 7 Battery Base
RZ - FF2 - 8 Motor
RZ - FF2 - 9 Fuselage / Plane Body
Note: Some parts are listed and shown for
illustration purposes only, and are not
available individually as replacement
parts.
REV 01c, 02a; 05c; 05j; 06e; 09a
IMPORTANT:
If damage is caused due to a crash, your warranty is void.
