The Functions
PSR-S550 Owner’s Manual 81
■ Function Setting List
Group Function Item
Display
Indication
Range/Settings Description
VOLUME Style Volume Style Volume 000–127 Determines the volume of the Style.
Song Volume Song Volume 000–127 Determines the volume of the Song.
OVERALL Tuning Tuning 415.3–466.2 Sets the pitch of the instrument’s sound.
Pitch Bend
Range
Pitch Bend
Range
01–12 Sets the pitch bend range in semitone increments.
Split Point Split Point 036–096
(C1–C6)
Determines the highest key for the Split Voice and sets
the Split “point”—in other words, the key that separates
the Split (lower) and Main (upper) Voices. The Split Point
setting and Accompaniment Split Point setting are auto-
matically set to the same value.
Touch Sensitivity Touch Sensitivity 1 (Soft),
2 (Medium),
3 (Hard)
Determines the sensitivity of the feature.
Chord Fingering Chord Fingering 1 (Multi Finger),
2 (FullKeyboard)
Sets the chord detection mode. In the Multi Finger mode
both normal chords and simple chords played to the left of
the split point are detected. In the Full Keyboard mode
normal chords played anywhere on the keyboard will be
detected, and the notes played will sound as well.
MAIN
VOICE
Volume Main Volume 000–127 Determines the volume of the Main Voice.
Octave Main Octave -2–+2 Determines the octave range for the Main Voice.
Pan Main Pan 000 (left)–
64 (center)–
127 (right)
Determines the pan position of the Main Voice in the ste-
reo image. The value “0” results in the sound being
panned full left; the value “127” results in the sound being
panned full right.
Reverb Level Main Reverb
Level
000–127 Determines how much of the Main Voice’s signal is sent to
the Reverb effect.
Chorus Level Main Chorus
Level
000–127 Determines how much of the Main Voice’s signal is sent to
the Chorus effect.
DSP Level Main DSP Level 000–127 Determines how much of the Main Voice’s signal is sent to
the DSP effect.
Dry Level Main Dry Level 000–127 Determines how much of the Main Voice’s unprocessed
signal sounds (no Reverb, Chorus or DSP effect process-
ing).
DUAL
VOICE
Volume Dual Volume 000–127 Determines the volume of the Dual Voice.
Octave Dual Octave -2–+2 Determines the octave range for the Dual Voice.
Pan Dual Pan 000 (left)–
64 (center)–
127 (right)
Determines the pan position of the Dual Voice in the ste-
reo image. The value “0” results in the sound being
panned full left; the value “127” results in the sound being
panned full right.
Reverb Level Dual Reverb
Level
000–127 Determines how much of the Dual Voice’s signal is sent to
the Reverb effect.
Chorus Level Dual Chorus
Level
000–127 Determines how much of the Dual Voice’s signal is sent to
the Chorus effect.
DSP Level Dual DSP Level 000–127 Determines how much of the Dual Voice’s signal is sent to
the DSP effect.
Dry Level Dual Dry Level 000–127 Determines how much of the Dual Voice’s unprocessed
signal sounds (no Reverb, Chorus or DSP effect process-
ing).
LEFT VOICE Volume Left Volume 000–127 Determines the volume of the Left Voice.
Octave Left Octave -2–+2 Determines the octave range for the Left Voice.
Pan Left Pan 000 (left)–
64 (center)–
127 (right)
Determines the pan position of the Left Voice in the stereo
image. The value “0” results in the sound being panned
full left; the value “127” results in the sound being panned
full right.
Reverb Level Left Reverb
Level
000–127 Determines how much of the Left Voice’s signal is sent to
the Reverb effect.
Chorus Level Left Chorus
Level
000–127 Determines how much of the Left Voice’s signal is sent to
the Chorus effect.
DSP Level Left DSP Level 000–127 Determines how much of the Left Voice’s signal is sent to
the DSP effect.
Dry Level Left Dry Level 000–127 Determines how much of the Left Voice’s unprocessed
signal sounds (no Reverb, Chorus or DSP effect process-
ing).
