5
Installation
continued
Safety Information
3
ConnecttheDB9portonthecomputertotheDB9portontheadapter
cable.
4
(Optional)ConnectalocalmonitortotheLocalVideoportontheLocal
UnitusingaVGAcable.
5
ConnecttheexternalpowersupplytothepowerjackontheLocalUnit
andplugitintoanappropriatepowersource.
6
ConnecttheRJ45
Link
portsoftheLocalandRemoteUnitsusing
Cat5/5e/6cable.
7
ConnecttheHD15portontheRemoteUnittoamonitor.
8
Connecttheincluded3.5mmMaletoDB9Maleadaptercabletothe
Serial
portontheRemoteUnit.
9
ConnecttheDB9MaleportontheadaptercabletotheDB9portofthe
serial deviceyouareconnecting(touch-screenmonitor,barcodescanner,etc.)
10
ConnecttheexternalpowersupplytothepowerjackontheRemote
Unitandplugitintoanappropriatepowersource.
11
Turnthedisplay(s)onfirst.
12
Turnonthecomputer.
13
Ifthevideoonyourmonitoriseithertoodarkortoolight,usethe
Gain
adjustmentontheRemoteUnit.
14
Ifthevideoonyourmonitorisfuzzy,orshowsaghostingeffect,usethe
EQadjustmentontheRemoteUnit.
• Toreducetheriskofelectricshock,donotexposethisproducttomoisture.
• Operatethisproductusingonlytheincludedexternalpowersupply.Use
ofotherpowersuppliescouldimpairperformance,damagetheproduct,
orcausefire.
• Useonlyrecommendedaccessoriestoavoidfire,shockorotherhazards.
• Unplugthisproductbeforecleaning.Useadampclothforcleaning.Do
notusecleaningfluidsoraerosols,whichcouldentertheunitandcause
damage,fireorelectricalshock.
• Donotattempttoservicethisunit.Instead,disconnectitandcontactyour
AuthorizedResellerortechnician.
