28 SSP-PRC001-EN
Table PD-33: Electric Heat Discharge Plenum and Grille Airflow (CFM)
Notes:
1 When wired for 460 Volt.
2 10 Ton with 6.5 inch sheave.
3 10 Ton with 8 inch sheave.
Table PD-34: Discharge Plenum and Grille Assembly Throw Distance (ft) - Air Handler
Throw distance values are based on a terminal velocity of 75 FPM.
Throw distance values at other terminal velocities may be established by multiplying throw distances in
the table above by throw factor:
Tons Unit Model No. Electric Heater
Model No.
Airflow (CFM)
Minimum Maximum
5 TWE060A1, B1 BAYHTRL117A 2000 2400
TWE060A3, B3 BAYHTRL315A 2000 2400
TWE060A4, B4 BAYHTRL415A 2000 2400
7 1/2 TWE090A1, B1
BAYHTRL117A 3000 3600
BAYHTRL123A 3375 3600
TWE090A3, B3
BAYHTRL315A 2625 3600
BAYHTRL325A 3000 3600
TWE090A3, B3
BAYHTRL415A 2625 3600
BAYHTRL425A 2625 3600
10 TWE120A1, B1
BAYHTRL117A 3500 4800
BAYHTRL123A 4000 4800
TWE120A3, B3
BAYHTRL315A 4000 4800
BAYHTRL325A 3500 4800
TWE120A3, B3
1
BAYHTRL415A 3500 4800
BAYHTRL425A 3500 4800
15
TWE180B3 BAYHTRM330A 5250 7200
TWE180B4 BAYHTRM430A 5250 7200
20
TWE240B3 BAYHTRM330A 7000 9600
TWE240B4 BAYHTRM430A 7000 9600
Unit Tons
Model No. CFM Louver Angle Deflection Position
Straight 20º 40º 55º
5
TWE060A
TWE060B
1600 42 31 26 20
1800 46 37 29 22
2000 48 43 33 24
2200 51 50 36 25
2400 54 57 39 29
TWE090A
TWE090B
2400 52 43 35 29
2700 55 48 38 31
3000 58 53 42 32
3300 62 57 46 35
3600 66 60 50 37
TWE120A
TWE120B
3200 56 46 38 30
3600 62 51 42 33
4000 66 57 47 35
4400 71 62 52 38
4800 76 67 56 42
15 TWE180B 4900 47 38 32 25
5400 52 44 37 29
6000 57 49 41 32
6600 61 53 43 34
7200 65 57 46 35
20 TWE240B 6400 56 46 38 30
7200 62 51 42 33
8000 66 57 47 35
8800 71 62 52 38
9600 76 67 56 42
Terminal Velocity Throw Factor
50 FPM x 1.50
100 FPM x .75
150 FPM x .50
Performance Data
5 - 20 Ton
