Specications
Power supply 12V DC ± 10 %, PoE
Consumption current 12V DC / 2.1 A
Image pickup device 1/3 inch (4:3), CMOS Digital Image Sensor
Full resolution (FULL HD) Horizontal 2048, vertical 1536 pixels
Scanning system Progressive
Motorized lens Max. Aperture F=1:1.8
Focal length f= 2.8mm to 12mm
Angle of view Wide end: horizontal 82° vertical 61°
Tele end: horizontal 29° vertical 22°
Day / Night Removable IR-Cut lter in Night mode
IR illuminator Adaptive IR function, Distance Max. 20m
Minimum object illuminance 0.03 lux / F1.8 (Night mode, LED-OFF, Gain control 100%,
Exposure time 1/30)
0 lux with IR illuminators
Noise Reduction 3D NR
Dynamic range True-WDR
White balance AWB (2,500K to 10,000K)
Image size of full view 2048x1536, 1920x1080, 1280x1024, 1280x720, 1024x768,
640x480, 320x240
Image compression system JPEG, H.264, and H.264 Smart Codec
Image rotation Flip, Mirror, and Hallway View
Maximum frame rate at M-JPEG (*1)
20 fps at 2048 x 1536, 30 fps at 1920 x 1080, 60 fps at
1280 x 720(WDR-OFF)
Maximum frame rate at H.264 (*1) 20 fps at 2048 x 1536, 30 fps at 1920 x 1080, 60 fps at
1280 x 720(WDR-OFF)
Digital zoom Maximum 12 times
Audio in / Audio out (*2) MIC IN (plug-in power 3.3V, 200kΩ) / LINE OUT (1 Vrms)
I/O terminal Input 1, output 1
Network interface 10Base-T / 100Base-TX, RJ45 connector,
IEEE 802.3af (PoE compatible)
Protocols IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/
RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS,
PPPoE, CoS, QoS, SNMP, and 802.1X
OS Windows Vista
®
Business, Windows
®
7 professional
Browser Internet Explorer
®
Ver. 8.0
ONVIF Prole-S (test tool v14.06)
Operating temperature (*3) PoE : -4°F to 122°F (-20°C to 50°C)
12V DC : -22°F to 122°F (-30°C to 50°C)
Operating humidity ~ 90 %
Weight 1310g (2.89 lbs)
Dimensions
Ф6.8 x 4.5(H) inches
(Ф173 x 115(H)mm) (excluding protrusion)
IP Code IP66
Vandal resistant IK10 (IEC62262)
Safety regulation UL 60950-1, CSA C22.2 No. 60950-1
EMC standard FCC Class A, IC Class A
Accessories Screws(x4), Anchors(x4), AV Out cable(x1), Mounting Plate
(x1), Gasket (x1), Torx Wrench (x1), Silica Gel and tape
(x1), Hex Nut (x1), Waterproof Connector (x1), Bushing (x1),
Alignment sticker(x1), CD-ROM(x1), Quick Start guide and
Important Safeguards(x1),Warranty Card(x1)
