5.17MACInterruptStatus(Unmasked)Register(MACINTSTATRAW)
5.18MACInterruptStatus(Masked)Register(MACINTSTATMASKED)
EthernetMediaAccessController(EMAC)Registers
TheMACinterruptstatus(unmasked)register(MACINTSTATRAW)isshowninFigure57and
describedinTable56.
Figure57.MACInterruptStatus(Unmasked)Register(MACINTSTATRAW)
3116
Reserved
R-0
15210
ReservedHOSTPENDSTATPEND
R-0R-0R-0
LEGEND:R=Readonly;-n=valueafterreset
Table56.MACInterruptStatus(Unmasked)Register(MACINTSTATRAW)FieldDescriptions
BitFieldValueDescription
31-2Reserved0Reserved
1HOSTPEND0-1Hostpendinginterrupt(HOSTPEND);rawinterruptread(beforemask)
0STATPEND0-1Statisticspendinginterrupt(STATPEND);rawinterruptread(beforemask)
TheMACinterruptstatus(masked)register(MACINTSTATMASKED)isshowninFigure58and
describedinTable57.
Figure58.MACInterruptStatus(Masked)Register(MACINTSTATMASKED)
3116
Reserved
R-0
15210
ReservedHOSTPENDSTATPEND
R-0R-0R-0
LEGEND:R=Readonly;-n=valueafterreset
Table57.MACInterruptStatus(Masked)Register(MACINTSTATMASKED)FieldDescriptions
BitFieldValueDescription
31-2Reserved0Reserved
1HOSTPEND0-1Hostpendinginterrupt(HOSTPEND);maskedinterruptread
0STATPEND0-1Statisticspendinginterrupt(STATPEND);maskedinterruptread
