60
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
AU SW
A-4428-791-A AU SW BOARD, COMPLETE
**********************
< CAPACITOR >
C1503 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1504 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C1505 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C1512 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C1521 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1524 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1525 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1526 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1527 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C1528 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1529 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C1530 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1531 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C1533 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C1535 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C1537 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C1539 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C1540 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C1541 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C1543 1-126-965-11 ELECT 22uF 20% 50V
C1546 1-126-965-11 ELECT 22uF 20% 50V
C1548 1-126-965-11 ELECT 22uF 20% 50V
C1550 1-126-965-11 ELECT 22uF 20% 50V
C1552 1-126-965-11 ELECT 22uF 20% 50V
C1554 1-126-965-11 ELECT 22uF 20% 50V
C1560 1-126-965-11 ELECT 22uF 20% 50V
C1561 1-126-965-11 ELECT 22uF 20% 50V
C1562 1-126-965-11 ELECT 22uF 20% 50V
C1563 1-126-965-11 ELECT 22uF 20% 50V
C1564 1-126-965-11 ELECT 22uF 20% 50V
C1565 1-126-965-11 ELECT 22uF 20% 50V
< CONNECTOR >
CNP10 1-784-927-11 PIN, CONNECTOR 12P
CNP11 1-764-867-41 CONNECTOR, BOARD TO BOARD 20P
CNP12 1-695-088-11 PIN, CONNECTOR (PC BOARD) 9P
< DIODE >
D1501 8-719-820-05 DIODE 1SS181-TE85L
D1504 8-719-820-05 DIODE 1SS181-TE85L
D1505 8-719-820-05 DIODE 1SS181-TE85L
< IC >
IC1502 8-759-590-10 IC TC9273F-012 (EL)
IC1505 8-759-099-06 IC M5218AFP-TE1
IC1506 8-759-099-06 IC M5218AFP-TE1
IC1507 8-759-099-06 IC M5218AFP-TE1
IC1508 8-759-099-06 IC M5218AFP-TE1
IC1509 8-759-099-06 IC M5218AFP-TE1
IC1510 8-759-099-06 IC M5218AFP-TE1
< TRANSISTOR >
Q1501 8-729-107-45 TRANSISTOR 2SC3624A-T1L15L16
Q1502 8-729-107-45 TRANSISTOR 2SC3624A-T1L15L16
Q1503 8-729-107-45 TRANSISTOR 2SC3624A-T1L15L16
Q1504 8-729-107-45 TRANSISTOR 2SC3624A-T1L15L16
Q1505 8-729-107-45 TRANSISTOR 2SC3624A-T1L15L16
Q1506 8-729-107-45 TRANSISTOR 2SC3624A-T1L15L16
Q1507 8-729-027-23 TRANSISTOR RT1P141C-TP-1
< RESISTOR >
R1501 1-216-295-00 SHORT 0
R1502 1-216-295-00 SHORT 0
R1504 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1508 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1509 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1510 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1512 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1513 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1514 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1515 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1516 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1517 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1528 1-216-033-00 METAL CHIP 220 5% 1/10W
R1529 1-216-033-00 METAL CHIP 220 5% 1/10W
R1530 1-216-033-00 METAL CHIP 220 5% 1/10W
R1532 1-216-085-00 METAL CHIP 33K 5% 1/10W
R1533 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1534 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1535 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1537 1-216-085-00 METAL CHIP 33K 5% 1/10W
R1538 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1539 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1541 1-216-085-00 METAL CHIP 33K 5% 1/10W
R1542 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1543 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1545 1-216-085-00 METAL CHIP 33K 5% 1/10W
R1546 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1547 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1549 1-216-085-00 METAL CHIP 33K 5% 1/10W
R1550 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1551 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1553 1-216-085-00 METAL CHIP 33K 5% 1/10W
R1554 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1556 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1559 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1560 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1561 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1562 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1563 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1564 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1565 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1567 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1568 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1569 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1578 1-216-033-00 METAL CHIP 220 5% 1/10W
R1579 1-216-033-00 METAL CHIP 220 5% 1/10W
R1580 1-216-033-00 METAL CHIP 220 5% 1/10W
R1581 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1582 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1583 1-216-097-00 RES-CHIP 100K 5% 1/10W
