31
GB
Using Optional Equipment
Connecting optional equipment
Using Optional Equipment
You can connect a wide range of optional equipment to your TV. Connecting cables are not supplied.
Connecting to the side of the TV
To connect Do this
S VHS/Hi 8/DVC
camcorder
A
Connect to the S video socket
4 or the video socket 4,
and the audio sockets 4. To
avoid picture noise, do not connect
the camcorder to the video socket
4 and the S video socket
4 at the same time. If you
connect mono equipment, connect
to the L/G/S/I sockets 4, and
set “Dual Sound” to “A”
(page 21).
Headphones
B Connect to the i socket to listen to
sound from the TV on headphones.
Headphones
S VHS/Hi8/DVC
camcorder
A
B
To connect Do this
Personal Computer
C
Connect to the PC Input socket
5 and the audio socket
G
on the rear of the TV (page 32).
C
Continued
