Auger Housing & Chute Group
Footnotes:
TP 400-5286-IR-LF-N
Manual No. 7006185LARGE FRAME TWO STAGE
2008 MODELS
11
Part No Descri
tionItem Qt
Note
33 1931353 2 CARRIAGE BOLT, 3/8-16 x 1-3/4
34 1733026 1 WASHER, Powdered Metal
35 1732238 1 CABLE, Chute Brake
37 1732837A 1 BRACKET, Brake
38 1732308 1 ARM & PAD ASSEMBLY, Brake
39 1679554 1 SPRING, Extension
40 1923282 1 CAPSCREW, Hex Head 1/4-20 x 2-1/2 G5
41 1922127 2 CAPSCREW, Hex Head 5/16-18 x 1-3/4
42 1923358 1 NUT, Hex Centerlock 1/4-20
43 1732231 1 ROD, Hex Chute
44 1722460 2 PIN, Quick
45 1732241 1 COVER, Chute
46 1732506 1 CHUTE & DEFLECTOR ASSEMBLY
47 1732028 1 BRACKET, Chute Support
48 1960252 2 CARRIAGE BOLT, 1/4-20 x 5/8 G5
49 1960294 2 NUT, Hex Flange 1/4-20 Whiz Lock
50 1732172A 1 RING, Chute Base
55 1960686 3 NUT, Hex Flange 5/16-18 ESNA
56 1733455 1 SPRING, Extension
57 1733082A 1 BRACKET, Cable
58 696239 1 KNOB & SCREW ASSEMBLY
59 1731942 2 NUT, Push Pal 3/8
61 1960593 1 NUT, Retainer Speed #10-24 w/Extrusion
62 1960680 2 NUT, Hex Keps Conical Washer 3/8-16
63 1960756 2 SCREW, Truss Head Trox Drive 5/16-18 x 3/4
66 7091542 3 SCREW, Pan Head Self Tap Torx 5/16-18 x 1/2
67 1931202 6 SCREW, Hex Washer head Taptite 5/16-18 x 1-1/4
68 1733476A 1 BRACKET, Chute Guard (CE/Export)
71 1960086 1 SCREW, Truss Head Torx 5/16-18 x 7/8
72 1733475 1 GUARD, Chute (CE/Export)
74 1960140 2 NUT, Push (CE/Export)
79 1734932A COVER, Bushing
