REFERENCE Transaxle Service Parts — Peerless Model MST 205-515B (Gear Models)
48 774869 1 Axle (16-13/16” long)
49 778356 1 Spur Gear (29 teeth-steel)
50 778354 1 Spur Gear (23 teeth-steel)
51 778352 1 Spur Gear (19 teeth-steel)
52 778350 1 Spur Gear (16 teeth-steel)
53 778346 1 Spur Gear (15 teeth-steel)
56 778355 1 Spur Gear (11 teeth-steel)
57 778353 1 Spur Gear (17 teeth-steel)
58 778351 1 Spur Gear (21 teeth-steel)
59 778349 1 Spur Gear (24 teeth-steel)
60 778345 1 Spur Gear (25 teeth)
63 786071 1 Countershaft Spacer 1-1/8” x 3/8”
64 786072 1 Brake Shaft Spacer 1-3/8” X 3/8”
65 780189 1 Washer
66 776394 1 Input Shaft
67 776396 1 Shifter & Brake Shaft
69 792170 1 Retaining Ring
70 786178 1 Spacer
71B 788092 1 “O” Ring
72A 788091 1 “O” Ring
72 792165 1 Threaded Plug 9/16-18
73 780140 2 Needle Bearing 3/4”
75 786084 2 Sleeve .999 ID
76 780090 1 Washer
77 788078A 1 Inverted Retaining Ring
82 778333 1 Bevel & Spur Gear (30 & 13 teeth)
83 778338 1 Spur Gear (27 teeth)
85 792154 1 Oil Fill Plug
87 788089 1 Oil Seal 9/16”
150 788093 1 Liquid Gasket RTV Silicone
157 788088 2 Oil Seal 3/4”
180 730229A 1 Gear Oil 80W90
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
Peerless transmission parts must be ordered through your local Tecumseh/Peerless distributor.
© Copyright 1998 Tecumseh Products Company. All Rights Reserved.
Reference Nos 1 through 47 are listed on the previous pages.
The above parts group applies to the following Mfg. Nos.:
1693074 Regent 14HP Gear
1693076 Regent 14HP Gear-Export
1693084 Regent 16HP Gear
1693086 Regent 16HP Gear-Export
1693092 514G, 14HP Gear
1693100 2514G, 14HP Gear
1693323 Regent 14HP Gear
1693331 Regent 14HP Gear-Export
1693339 514G, 14HP Gear
1693345 2514G, 14HP Gear
