Introduction
14
When shooting with the viewfinder, the following information
appears in the viewfinder.
t Memo
• The information is displayed in the viewfinder when the
shutter release button is pressed halfway, or during the meter
operating time (default setting: 10 sec.).
• The AF point in use for autofocus appears in red
(Superimpose AF Area) when the shutter release button is
pressed halfway. You can set it to [Off] in [14. Superimpose
AF Area] of the E2 menu.
• You can adjust the diopter in the
viewfinder using the diopter
adjustment dial. Adjust the dial until
the AF frame in the viewfinder is
focused.
9 Aperture value 12 Histogram (R)
10 Sensitivity 13 Histogram (G)
11 EV Compensation 14 Histogram (B)
Viewfinder
1 AF frame (p.32) 11 Sensitivity (p.39)/
Exposure compensation
value
2 Spot metering frame
(p.40)
3 AF point (p.44) 12 AE Lock
4 Flash indicator (p.41) 13 Change AF Point (p.44)
5 Focus Method (p.42) 14 Multi-exposure (p.50)
6 Shutter speed 15 AE Metering (p.40)
7 Aperture value 16 Shake Reduction
8 Focus indicator 17 Flash Exposure
Compensation (p.41)
9 EV bar scale/Electronic
Level (p.15) 18 EV Compensation
(p.37)/Exposure
Bracketing (p.49)
10 ISO/ISO AUTO
19 File Format (p.35)
1
4
19
181716151413
61011
12
2
1
3
5 7 8 9
