8/38
FV-G200B1
User’s Guide Rev. 1.02
2.2.2 1/2 Partial Scanning
1 H = 52.1472 μs, 30.63336 Hz
2.2.3 1/4 Partial Scanning
1 H = 52.1472 μs, 61.26674 Hz
232H
Video out
Vertical blanking
3
1
3
H
One vertical (1V)
232H
8
1
H
81H
Video output
733
734
503
504
FVAL
81H
8
1
H
LVAL
DVAL
570H
Video out
Vertical blanking
6
2
6
H
One vertical (1V)
56H56H
Video output
902
903
334
335
FVAL
570H56H
5
6
H
LVAL
DVAL
