Inserting the Ink Cassette
1
After removing the stopper 1, turn the
hole in the direction of the arrow to clear
any slack in the Ink Film.
2
Open Ink Cassette Compartment Door
2.
3
Push it into the direction shown by the
arrow until it clicks into place.
4
Close 2.
Ejecting the Ink Cassette
Slide the Ink Cassette Eject Lever
3
to take out
the Ink Cassette.
≥Do not touch the Ink Film in the Ink Cassette, and do
not pull it out of the cassette.
≥It is recommended that you do not pull out the Ink
Cassette before the full consumption of ink, because
the Ink Film may sag when resetting the Ink
Cassette.
≥Confirm that there is no paper and then remove or
replace the Ink Cassette.
≥Do not eject the Ink Cassette during printing.
≥Close the Ink Cassette Compartment Door during
printing.
≥After removing the Ink Cassette, pack it back into its
original case.
