【#3052】 spplr Spindle motor spindle relative polarity
Set the spindle motor and spindle's relative polarity.
0: Positive polarity
Spindle CW rotation at motor CW rotation
1: Negative polarity
Spindle CCW rotation at motor CW rotation
---Setting range---
0000/0001 (HEX)
【#3053】 sppst Spindle encoder Z -phase position
Set the deviation amount from the spindle's basic point to the spindle detector's Z phase.
Obtain the deviation amount, considering a clockwise direction as positive when viewed from the
spindle's front side.
---Setting range---
0 to 359999 (1/1000°)
【#3054】 sptc1 Spindle synchronization multi-step acceleration/deceleration changeover
speed 1
Set the spindle speed for changing the 1st step's acceleration/deceleration time constant.
---Setting range---
0 to 99999 (r/min)
【#3055】 sptc2 Spindle synchronization multi-step acceleration/deceleration changeover
speed 2
Set the spindle speed for changing the 2nd step's acceleration/deceleration time constant.
---Setting range---
0 to 99999 (r/min)
【#3056】 sptc3 Spindle synchronization multi-step acceleration/deceleration changeover
speed 3
Set the spindle speed for changing the 3rd step's acceleration/deceleration time constant.
---Setting range---
0 to 99999 (r/min)
【#3057】 sptc4 Spindle synchronization multi-step acceleration/deceleration changeover
speed 4
Set the spindle speed for changing the 4th step's acceleration/deceleration time constant.
---Setting range---
0 to 99999 (r/min)
【#3058】 sptc5 Spindle synchronization multi-step acceleration/deceleration changeover
speed 5
Set the spindle speed for changing the 5th step's acceleration/deceleration time constant.
---Setting range---
0 to 99999 (r/min)
【#3059】 sptc6 Spindle synchronization multi-step acceleration/deceleration changeover
speed 6
Set the spindle speed for changing the 6th step's acceleration/deceleration time constant.
---Setting range---
0 to 99999 (r/min)
