Wireless Network PC Card
10
Instant Wireless
®
Series
9
Chapter 5:Hardware Installation
1. Turn off your notebook PC.
2. Locate an available PCMCIA slot on your notebook PC.
3. With the PC Card’s
label facing up, as
shown in Figure 5-1,
slide the PC Card
completely into the
PCMCIA slot.
4. Restart your note-
book PC.
5. Windows will begin copying the driver files to your computer. If Windows
asks you for the original Windows CD-ROM, insert the CD-ROM, and
direct Windows to its proper location (e.g., D:\).
If your PC is using Windows 98SE, Me, or 2000, proceed to the next sec-
tion, “Chapter 7: Using the WLAN Monitor for Windows 98SE, Me, and
2000.”
If your PC is using Windows XP, proceed to “Chapter 6: Driver
Installation and Configuration for Windows XP.”
Figure 5-1
Important for Windows 98SE, Me, and 2000 users: You must run
the Setup Wizard to install the software before installing the hardware.
Important for Windows XP users: You must install the PC Card’s
hardware before installing the software.
5. The next screen, shown in Figure 4-5, will ask you to review your settings
before it starts to copy files. Click the Next button to save these settings, or
click the Back button to change any settings.
6. After the files have been successfully copied, the screen in Figure 4-6 will
appear. Click the Exit button.
Proceed to “Chapter 5: Hardware Installation.”
Figure 4-6
Figure 4-5
