6 English
To avoid accidents due to electrical faults
we recommend the use of sockets with a
line-side current-limiting circuit breaker
(max. 30 mA nominal tripping current).
ƽ Caution
Certain materials may produce explosive
vapours or mixtures when agitated by the
suction air!
Never vacuum up the following materials:
– Explosive or combustible gases, liquids
and dust particles (reactive dust particles)
– Reactive metal dust particles (such as
aluminium, magnesium, zinc) in combi-
nation with highly alkaline or acidic de-
tergents
– Undiluted, strong acids and alkalies
– Organic solvents (such as petrol, paint
thinners, acetone, heating oil).
In addition, these substances may cause
the appliance materials to corrode.
Illustrations on fold-out page!
These operating instructions
describe the basic models of the Multi-
Purpose Vacs shown on the front cover.
The illustrations show the maximum
equipment; depending on the model,
there are differences in equipment and
supplied accessories.
When unpacking the product, make sure
that no accessories are missing and that
none of the package contents have been
damaged. If you detect any transport dam-
ages please contact your dealer.
included in the scope of delivery
possible accessories
To connect the suction hose during vac-
uuming.
(see description / illustration )
Position I: Suction or blowing
Position 0: Appliance is switched off
Position I: Suction or blowing
Position II: Automatic vacuuming with
connected electric tool
Position 0: Appliance and the connect-
ed electric tool are switched off
Note: Observe the maximum connected
power (see Chapter "Specifications").
To connect an electric tool.
(see description / illustration )
Transport the appliance using the carry-
ing handle.
To store the mains cable.
(see description / illustration )
Connect the suction hose to the blower
connection, this will activate the blower
function.
(see description / illustration )
Pull out to open, push in to lock.
(see description / illustration )
To rest the floor nozzle during work in-
terruptions.
(see description / illustration )
The accessories compartment allows
the storage of suction pipes and suction
nozzles on the appliance.
(see description / illustration )
The steering rollers are located in the
compartment when the appliance is de-
livered. These must be attached prior to
starting up the appliance.
(see description / illustration )
Description of the Appliance
Suction hose connection
ON/OFF switch for appliance
(without built-in socket)
ON/OFF switch for appliance
(with built-in socket)
Machine socket
Carrying handle
Cable hook
Blowing connection
Container closure
Parking position
Accessory mount
Steering roller
